Specifications:
Monocrystalline silicon solar cell 125mm×125mm
No. of cells 72pcs (6×12)
Dimension 1580mm×808mm×35mm
Weight 15kg
Tolerance ±3%
Characteristics
Module
ST180M-72
ST185M-72
ST190M-72
ST195M-72
Open Circuit Voltage (Voc)
43.2V
43.3V
43.6V
Short Circuit Current (Isc)
5.6A
5.77A
5.85A
5.96A
Maximum Power Voltage (Vmp)
36.0V
36.2V
36.3V
36.4V
Maximum Power Current (Imp)
5.0A
5.11A
5.24A
5.36A
Module Efficiency
14.10%
14.49%
14.88%
15.27%
Maximum Power(Pm)
180Wp
185Wp
190Wp
195Wp
STC: Irradiance 1000W/m2 Module temperature 25℃ AM=1.5
Operating temperature -40℃—+85℃
Maximum system voltage 1000VDC
TEMPERATURE & COEFFICIENCY
NOTC 48℃±2℃
Temp. Coeff. Of Isc (TK Isc) (0.065±0.015)%/ ℃
Temp. Coeff. Of Voc (TK Voc) -0.33%/ ℃
Temp. Coeff. Of Pmax (TK Pmax) -(0. 4±0.05)%/ ℃
Max wind resistance capacity 60m/s
Max load capacity 200kg/ m2
Max hail diameter at 80km/h 25mm
NOCT: Nominal operation cell temperature
